Claw clamp, aluminum EN AW-6061 | screw: stainless steel A2-70

Zinc-plated and stainless steel versions: Suitable for use with metal and elastomer seals
Aluminum version: Suitable for use with elastomer seals
For installing an ISO-K flange on a base plate with a centering ring lying on it
For a base plate with O-ring groove, please use the shorter claw clamp for the base plate with the sealing groove (BPD)
Not to be used for the installation of turbo pumps! Use the fastening elements given in the corresponding operating instructions.

310BPR100

Global-No. 2000043205

Zinc-plated and stainless steel versions: Suitable for use with metal and elastomer seals
Aluminum version: Suitable for use with elastomer seals
For installing an ISO-K flange on a base plate with a centering ring lying on it
For a base plate with O-ring groove, please use the shorter claw clamp for the base plate with the sealing groove (BPD)
Not to be used for the installation of turbo pumps! Use the fastening elements given in the corresponding operating instructions.
Delivery time: 1-3 days

Order number	Delivery time	Your price	Amount
310BPR100 Global-No. 2000043205	1-3 days	€3.30

Connection flange	DN 63 – DN 100 ISO-K
Material	Aluminum EN AW-6061 screw: stainless steel A2-70
Temperature range	-196 – 200 °C

Name	Category	Language	Filesize
Pratze Datasheet_310BPR100_de.pdf	Datasheet	German	341 kB
Claw clamp Datasheet_310BPR100_en.pdf	Datasheet	English	326 kB
3D Step 310BPR100.stp	3D CAD		172 kB
