Connection flange	A [mm]	B [mm]	C [mm]	D	Pipe dimension	Order number	Delivery time	Your price
DN 16 CF	7.75 mm	16 mm	18.15 mm	M4	18 mm × 1 mm	420FAN016-18-G	1-3 days	€16.00
DN 25 CF	12 mm	24 mm	28.2 mm	M6	28 mm × 2 mm	420FAN025-28-G	1-3 days	€28.00
DN 40 CF	12.7 mm	35 mm	38.2 mm	M6	38 mm × 1.5 mm	420FAN040-38-G	1-3 days	€21.00
DN 40 CF	12.7 mm	37 mm	40.2 mm	M6	40 mm × 1.5 mm	420FAN040-40-G	1-3 days	€21.00
DN 40 CF	12.7 mm	38.4 mm	42.6 mm	M6	42.4 mm × 2 mm	420FAN040-42-G	1-3 days	€21.00
DN 40 CF	12.7 mm	40.5 mm	44.7 mm	M6	44.5 mm × 2 mm	420FAN040-44-G	1-3 days	€21.00
DN 63 CF	17.5 mm	66 mm	70.3 mm	M8	70 mm × 2 mm	420FAN063-70-G	1-3 days	€76.00
DN 100 CF	19.8 mm	100 mm	104.3 mm	M8	104 mm × 2 mm	420FAN100-104-G	1-3 days	€129.00
DN 100 CF	19.8 mm	104 mm	108.3 mm	M8	108 mm × 2 mm	420FAN100-108-G	1-3 days	€119.00
DN 160 CF	22.2 mm	150 mm	154.3 mm	M8	154 mm × 2 mm	420FAN160-154-G	1-3 days	€177.00
DN 160 CF	22.2 mm	155 mm	159.3 mm	M8	159 mm × 2 mm	420FAN160-159-G	1-3 days	€177.00
DN 200 CF	24.5 mm	200 mm	204.3 mm	M8	204 mm × 2 mm	420FAN200-204-G	On request	€275.00
DN 200 CF	24.5 mm	200 mm	205.3 mm	M8	205 mm × 2.5 mm	420FAN200-205-G	1-3 days	€290.00
DN 250 CF	26 mm	250 mm	254.3 mm	M8	254 mm × 2 mm	420FAN250-254-G	1-3 days	€495.00
DN 250 CF	26 mm	250 mm	256.3 mm	M8	256 mm × 3 mm	420FAN250-256-G	On request	€485.00
DN 300 CF	28.5 mm	300 mm	306.3 mm	M10	306 mm × 3 mm	420FAN300-306-G	On request	€795.00

Stainless steel 304L, with imperial (UN) thread

Connection flange	A [mm]	B [mm]	C [mm]	D	Pipe dimension	Order number	Delivery time	Your price
DN 16 CF	7.75 mm	15.75 mm	19.2 mm	8-32	19.05 mm × 1.65 mm	420FAN016-19-T	1-3 days	€19.00
DN 25 CF	12 mm	22.1 mm	25.6 mm	1/4"-28	25.4 mm × 1.65 mm	420FAN025-25-T	On request	€29.00
DN 40 CF	12.7 mm	35 mm	38.2 mm	1/4"-28	38 mm × 1.5 mm	420FAN040-38-T	1-3 days	€24.00
DN 40 CF	12.7 mm	40.5 mm	44.7 mm	1/4"-28	44.5 mm × 2 mm	420FAN040-44-T	1-3 days	€28.00
DN 50 CF	17.3 mm	47.5 mm	51.1 mm	5/16"-24	50.8 mm × 1.65 mm	420FAN050-50-T	1-3 days	€46.00
DN 63 CF	17.5 mm	60.2 mm	63.8 mm	5/16"-24	63.5 mm × 1.65 mm	420FAN063-63-T	1-3 days	€82.00
DN 75 CF	17.5 mm	72.1 mm	76.4 mm	5/16"-24	76.1 mm × 2 mm	420FAN075-76-T	On request	€95.00
DN 100 CF	19.8 mm	97.4 mm	101.9 mm	5/16"-24	101.6 mm × 2.1 mm	420FAN100-101-T	1-3 days	€131.00
DN 130 CF	21.4 mm	123.7 mm	127.3 mm	5/16"-24	127 mm × 1.65 mm	420FAN130-127-T	On request	€158.00
DN 160 CF	22.2 mm	147.6 mm	152.7 mm	5/16"-24	152.4 mm × 2.4 mm	420FAN160-152-T	1-3 days	€190.00
DN 200 CF	24.5 mm	198.4 mm	203.5 mm	5/16"-24	203.2 mm × 2.4 mm	420FAN200-203-T	1-3 days	€300.00
DN 250 CF	26 mm	250 mm	254.3 mm	5/16"-24	254 mm × 2 mm	420FAN250-254-T	1-3 days	€520.00

‹ › ×
