Magnetically coupled Rotary Feedthrough
Product description
- Magnetic coupling with samarium-cobalt magnets
- Stainless steel ball bearing with dry lubrication suitable for UHV
- Hermetically sealed, suitable for UHV
- Fixing brake
Subcategories
Die Filterung ergab Treffer
Technical Data
- Bakeout temperature max.: ≤ 200 °C
- Operating temperature: ≤ 60 °C
- Tightness: 1 · 10-11 Pa m³/s
- Angle of rotation: 360°
- Pressure range: 1E-10 hPa – 5E2 hPa over pressure
- Scale: (DN 40) Accuracy of reading 1/10°
- Ambient temperature: -10 – 50 °C
- Shaft connection: With threaded hole, vented: DN 16: M3 x 6 | DN 40: M5 x 10
