Connection flange	A [mm]	B [mm]	C [mm]	D [mm]	E [mm]	Pipe dimension	Order number	Delivery time	Your price
DN 63 ISO-K	95	70	12	63.8	7	63.5 mm × 1.65 mm	320FAN063-63	1-3 days	€35.00
DN 63 ISO-K	95	70	12	70.3	7	70 mm × 2 mm	320FAN063-70	1-3 days	€30.00
DN 63 ISO-K	95	70	12	76.4	6	76.1 mm × 3 mm	320FAN063-76	1-3 days	€30.00
DN 63 ISO-K	95	70	12	76.4	8	76.1 mm × 3 mm	320FAN063-76-S	1-3 days	€32.00
DN 80 ISO-K	110	83	12	76.4	7	76.1 mm × 3 mm	320FAN080-76	On request	€52.00
DN 80 ISO-K	110	83	12	89.2	6	88.9 mm × 3 mm	320FAN080-88	1-3 days	€37.00
DN 100 ISO-K	130	102	12	101.9	7	101.6 mm × 2.1 mm	320FAN100-101	1-3 days	€37.00
DN 100 ISO-K	130	102	12	104.3	7	104 mm × 2 mm	320FAN100-104	1-3 days	€35.00
DN 100 ISO-K	130	102	12	108.3	6	108 mm × 3 mm	320FAN100-108	1-3 days	€37.00
DN 100 ISO-K	130	102	12	108.3	8	108 mm × 3 mm	320FAN100-108-S	1-3 days	€39.00
DN 100 ISO-K	130	102	12	114.6	6	114.3 mm × 2 mm	320FAN100-114	1-3 days	€49.00
DN 160 ISO-K	180	153	12	152.7	7	152.4 mm × 2.4 mm	320FAN160-152	1-3 days	€63.00
DN 160 ISO-K	180	153	12	159.3	6	159 mm × 3 mm	320FAN160-159	1-3 days	€55.00
DN 160 ISO-K	180	153	12	159.3	8	159 mm × 3 mm	320FAN160-159-S	1-3 days	€60.00
DN 200 ISO-K	240	213	12	203.6	7	203.2 mm × 2.4 mm	320FAN200-203	1-3 days	€161.00
DN 200 ISO-K	240	213	12	219.4	6	219 mm × 3 mm	320FAN200-219	1-3 days	€156.00
DN 200 ISO-K	240	213	12	219.4	8	219 mm × 3 mm	320FAN200-219-S	1-3 days	€161.00
DN 250 ISO-K	290	261	12	254.4	7	254 mm × 2 mm	320FAN250-254	On request	€200.00
DN 250 ISO-K	290	261	12	273.4	6	273 mm × 3 mm	320FAN250-273	1-3 days	€200.00
DN 250 ISO-K	290	261	12	273.4	8	273 mm × 3 mm	320FAN250-273-S	1-3 days	€215.00
DN 320 ISO-K	370	318	17	324.4	8	324 mm × 3 mm	320FAN320-324	1-3 days	€465.00
DN 320 ISO-K	370	318	17	324.4	10	324 mm × 3 mm	320FAN320-324-S	On request	€475.00
DN 400 ISO-K	450	400	17	406.5	8	406 mm × 3 mm	320FAN400-406	1-3 days	€655.00
DN 500 ISO-K	550	501	17	508.5	8	508 mm × 4 mm	320FAN500-508	1-3 days	€890.00
DN 600 ISO-K	690	651	22	660.5	12	660 mm × 5 mm	320FAN630-660	1-3 days	€1,550.00

Stainless steel 1.4404/316L

Technical Data

Pressure range: 1E-8 hPa – 1.5E3 hPa over pressure (elastomer seal); 1E-9 hPa – 1.5E3 hPa over pressure (metal seal)
Temperature range: -196 – 350 °C

Connection flange	A [mm]	B [mm]	C [mm]	D [mm]	E [mm]	Pipe dimension	Order number	Delivery time	Your price
DN 63 ISO-K	95	70	12	63.8	7	63.5 mm × 1.65 mm	370FAN063-63	1-3 days	€39.00
DN 63 ISO-K	95	70	12	70.3	7	70 mm × 2 mm	370FAN063-70	1-3 days	€34.00
DN 63 ISO-K	95	70	12	76.4	6	76.1 mm × 3 mm	370FAN063-76	1-3 days	€34.00
DN 63 ISO-K	95	70	12	76.4	8	76.1 mm × 3 mm	370FAN063-76-S	1-3 days	€37.00
DN 80 ISO-K	110	83	12	76.4	7	76.1 mm × 3 mm	370FAN080-76	On request	€39.00
DN 80 ISO-K	110	83	12	89.2	6	88.9 mm × 3 mm	370FAN080-88	1-3 days	€39.00
DN 100 ISO-K	130	102	12	101.9	7	101.6 mm × 2.1 mm	370FAN100-101	1-3 days	€48.00
DN 100 ISO-K	130	102	12	104.3	7	104 mm × 2 mm	370FAN100-104	1-3 days	€44.00
DN 100 ISO-K	130	102	12	108.3	6	108 mm × 3 mm	370FAN100-108	1-3 days	€44.00
DN 100 ISO-K	130	102	12	108.3	8	108 mm × 3 mm	370FAN100-108-S	1-3 days	€48.00
DN 100 ISO-K	130	102	12	114.6	6	114.3 mm × 2 mm	370FAN100-114	1-3 days	€53.00
DN 160 ISO-K	180	153	12	159.3	6	159 mm × 3 mm	370FAN160-159	1-3 days	€62.00
DN 160 ISO-K	180	153	12	159.3	8	159 mm × 3 mm	370FAN160-159-S	1-3 days	€68.00
DN 200 ISO-K	240	213	12	203.6	7	203.2 mm × 2.4 mm	370FAN200-203	1-3 days	€161.00
DN 200 ISO-K	240	213	12	219.4	6	219 mm × 3 mm	370FAN200-219	1-3 days	€161.00
DN 250 ISO-K	290	261	12	254.4	7	254 mm × 2 mm	370FAN250-254	1-3 days	€205.00
DN 250 ISO-K	290	216	12	273.4	6	273 mm × 3 mm	370FAN250-273	1-3 days	€205.00
DN 320 ISO-K	370	318	17	324.4	8	324 mm × 3 mm	370FAN320-324	1-3 days	€485.00
DN 400 ISO-K	450	400	17	406.5	8	406 mm × 3 mm	370FAN400-406	1-3 days	€740.00
DN 500 ISO-K	550	501	17	508.5	8	508 mm × 4 mm	370FAN500-508	1-3 days	€1,070.00
