Magnetically coupled Rotary Feedthrough

Product description

  • Magnetic coupling with samarium-cobalt magnets
  • Stainless steel ball bearing with dry lubrication suitable for UHV
  • Hermetically sealed, suitable for UHV
  • Fixing brake

Die Filterung ergab Treffer

Technical Data

  • Bakeout temperature max.: ≤ 200 °C
  • Operating temperature: ≤ 60 °C
  • Tightness: 1 · 10-11 Pa m³/s
  • Angle of rotation: 360°
  • Pressure range: 1E-10 hPa – 5E2 hPa over pressure
  • Scale: (DN 40) Accuracy of reading 1/10°
  • Ambient temperature: -10 – 50 °C
  • Shaft connection: With threaded hole, vented: DN 16: M3 x 6 | DN 40: M5 x 10
€2,150.00
€2,950.00
