PCR 280, 80 °C
- Metal sealed
- Bakeout temperature: 80 °C
- Order number: PT R26 855
- Metal sealed
- Bakeout temperature: 80 °C
- Delivery time: 1-3 days
| Connection flange | DN 16 ISO-KF |
|---|---|
| Output signal: Measuring range | 1.2 – 8.68 V |
| Output signal: Minimum load | 10 kΩ |
| Bakeout temperature max. | ≤ 80 °C |
| Seal |
|
| Pressure max. | 5000 hPa |
| Feedthrough |
|
| Attribute | Stainless steel, metal sealed |
| Input voltage(s) | 15 – 30 V DC |
| Flange, material | Stainless steel |
| Weight | 0.12 kg |
| Filament | Tungsten |
| Power consumption max. | 2.5 W |
| Measuring range | 5E-5 – 1.5E3 hPa |
| Accuracy of measurement in range 1 | 50 % (5E-4 hPa – 1E-3 hPa) |
| Accuracy of measurement in range 2 | 15 % (1E-3 hPa – 1E2 hPa) |
| Accuracy of measurement in range 3 | 5 % (1E2 hPa – 9.5E2 hPa) |
| Accuracy of measurement in range 4 | 2.5 % (of measured value) (9.5E2 hPa – 1.05E3 hPa) |
| Measurement cable length | 100 m |
| Measuring method |
|
| Temperature: Storage | -20 – 65 °C |
| Ambient temperature | 10 – 50 °C |
| Volume | 4.7 cm³ |
| Repeatability in range 1 | 2 % (1E-3 hPa – 1.1E3 hPa) |
