PKR 361, high current
- The maximum pressure applies to inert gases and temperatures below 55 °C
- Rugged and dependable
- Insensitive to air ingress
- Without elastomer seal
- High current version optimized for high vacuum applications
- Order number: PT T03 140 010
- The maximum pressure applies to inert gases and temperatures below 55 °C
- Rugged and dependable
- Insensitive to air ingress
- Without elastomer seal
- High current version optimized for high vacuum applications
- Delivery time: 1-3 days
| Anode |
|
|---|---|
| Output signal: Measuring range | 2 – 8.6 V |
| Output signal: Minimum load | 10 kΩ |
| Bakeout temperature | Electronics removed 150 °C |
| Pressure max. | 10000 hPa |
| Feedthrough | Glass |
| Flange, material | Stainless Steel 1.4435 |
| Precision: 1 · 10<sup>-8</sup> – 1 · 100 hPa | ± 30 % |
| Weight | 280 g |
| Filament | Tungsten |
| Measuring range | 1E-9 – 1E3 hPa |
| Measurement cable length | 300 m |
| Measuring method | Pirani/Cold Cathode |
| Nominal diameter | DN 25 ISO-KF |
| Temperature: Storage | -40 – 70 °C |
| Ambient temperature | 5 – 55 °C |
| Supply: Voltage V DC | 14.5 – 30 V DC |
| Supply: consumption max. | 2 W |
| Volume | 19.9 cm³ |
| Repeatability: 1 · 10<sup>-8</sup> – 100 hPa | ± 5 % |
