Bellows, stainless steel: flange 1.4301/304; bellows 316L
- Flange connection length 15 mm
- Custom lengths on request
-
170SFK025-060
- Flange connection length 15 mm
- Custom lengths on request
- Delivery time: 1-3 days
Global-No. 2000044729
| Connection flange | DN 25 ISO-KF |
|---|---|
| Axial stroke | ± 5 mm |
| Tightness | 1 · 10-11 Pa m³/s |
| Pressure range | 1E-8 hPa – 5E2 hPa over pressure |
| Material | Flange: stainless steel 1.4301/304; bellows: stainless steel 316L |
| Specific Dimensions or Numbers | Length 60 mm |
| Service life | 10000 cycles |
| Temperature range | -196 – 300 °C |
| mm | |
|---|---|
| A | 60 |
| B | 24 |
| C | 39 |
