Measurement flange, Aluminum

DN 100 ISO-F with M8 tapped holes
With lateral DN 16 KF gauge head connection, including compression-fit clamping screws

PF 308 010 -T

Global-No. 2000026181

DN 100 ISO-F with M8 tapped holes
With lateral DN 16 KF gauge head connection, including compression-fit clamping screws
Delivery time: On request

Order number	Delivery time	Your price	Amount
PF 308 010 -T Global-No. 2000026181	On request	€380.00

Connection flange	DN 100 ISO-F
Pressure range	1E-8 hPa – 5E2 hPa over pressure
Thread	8 x M8
Materials in contact with media	Aluminum
Temperature range	196 – 200 °C

Name	Category	Language	Filesize
3D Step PF%20308%20010%20-T.stp	3D CAD		311 kB
