Viewport, DN 100 ISO-F, with safety glass
- Sight glasses with replaceable safety glass, especially suitable for coating systems
- With integrated FKM O-ring, installation without additional seal
- Including claw clamps, bolts, washers and nuts for installation
- For visually monitoring a process in a vacuum chamber
- Wide viewing angle
- Replaceable safety glass
- Caution! Risk of injury by glass splinters. Do not use viewports which show apparent damage
-
PF 411 013 -T
- Sight glasses with replaceable safety glass, especially suitable for coating systems
- With integrated FKM O-ring, installation without additional seal
- Including claw clamps, bolts, washers and nuts for installation
- For visually monitoring a process in a vacuum chamber
- Wide viewing angle
- Replaceable safety glass
- Caution! Risk of injury by glass splinters. Do not use viewports which show apparent damage
- Delivery time: 1-3 days
Global-No. 2000026284
| Connection flange | DN 100 ISO-F |
|---|---|
| Heat up and cool down rate | ≤ 5 K/min |
| Tightness | 1 · 10-10 Pa m³/s |
| Seal | FKM |
| Pressure range | 1E-8 hPa – 5E2 hPa over pressure (at temperatures > 60 °C only to ambient pressure) |
| Flange, material | Anodized aluminum, black |
| Weight | 1.4 kg |
| Glass thickness | 11 mm |
| Sight glass | Borosilicate |
| Safety glass thickness | 2.5 mm |
| Temperature range | 15 – 150 °C |
| mm | |
|---|---|
| A | 22 |
| B | 92 |
| C | 100 |
