EVB 160 PA, Angle valve
- Bellows-sealed
- With visual position indicator
- Normally closed (n. c.)
- Service life: 1 million operating cycles
-
310VEP160-02
- Bellows-sealed
- With visual position indicator
- Normally closed (n. c.)
- Service life: 1 million operating cycles
- Delivery time: On request
Global-No. 2000042315
| Connection flange | DN 160 ISO-K |
|---|---|
| Actuator | Electro-pneumatic |
| Bakeout temperature: actuator, pilot valve | 50 °C |
| Bakeout temperature: housing | 150 °C |
| Operating pressure min. | 1 · 10-8 hPa |
| Tightness | 1 · 10-10 Pa m³/s |
| Seal |
|
| Differential pressure in opening direction | 1200 hPa |
| Differential pressure in closing direction | 2000 hPa |
| Pressure max. (absolute) | 2000 hPa |
| Compressed air (overpressure) | 4500 – 7000 hPa |
| Feedthrough |
|
| Input voltage(s) | 24 V DC |
| Housing |
|
| Weight | 13.8 kg |
| Conductance value with molecular flow | 1000 l/s |
| Service life | 1000000 cycles |
| Position indicator |
|
| Position indicator: Load capacity | ≤ 50 V AC / DC | 5 – 100 mA |
| Control valve | Included |
| Type | Angle valve |
| mm | |
|---|---|
| A | 3.81 |
| B | 220 |
| C | 248 |
| D | 138 |
