EVI 005 S, Mini angle valve
- Two connections required as accessories
- Bellows-sealed
- Service life: 1.5 million operating cycles
-
Order number:
PF H12 031
- Two connections required as accessories
- Bellows-sealed
- Service life: 1.5 million operating cycles
-
Delivery time:
On request
| Actuator |
|
|---|
| Bakeout temperature: actuator |
70 °C
|
|---|
| Bakeout temperature: housing |
150 °C
|
|---|
| Operating pressure min. |
1 · 10-8 hPa
|
|---|
| Tightness |
1 · 10-10 Pa m³/s
|
|---|
| Seal |
|
|---|
| Differential pressure in opening direction |
4000 hPa
|
|---|
| Differential pressure in closing direction |
4000 hPa
|
|---|
| Pressure max. (absolute) |
4000 hPa
|
|---|
| Feedthrough |
Bellows, stainless steel
|
|---|
| Housing |
Stainless steel
|
|---|
| Weight |
150 g
|
|---|
| Conductance value with laminar flow |
4 l/s
|
|---|
| Conductance value with molecular flow |
0.4 l/s
|
|---|
| Nominal diameter |
DN 5 mm M14x1
|
|---|
| Opens against differential pressure of |
4 000 hPa
|
|---|
| Service life |
1500000 cycles
|
|---|
| Type |
Mini angle valve
|
|---|
| Ambient temperature |
5 – 70 °C
|
|---|
| Valve plate |
Stainless steel
|
|---|
