DVI 005 M, Mini-inline-valve
- Two connections required as accessories
- Service life: 2 million operating cycles
- Variants: DVI 005 M = normally closed (n. c.); DVI 205 M = normally open (n. o.)
-
Order number:
PF H13 232
- Two connections required as accessories
- Service life: 2 million operating cycles
- Variants: DVI 005 M = normally closed (n. c.); DVI 205 M = normally open (n. o.)
-
Delivery time:
On request
| Connection flange |
DN 5 mm M14x1 Thread
|
|---|
| Actuator |
|
|---|
| Bakeout temperature: actuator |
120 °C
|
|---|
| Bakeout temperature: housing |
150 °C
|
|---|
| Operating pressure min. |
1 · 10-8 hPa
|
|---|
| Tightness |
1 · 10-10 Pa m³/s
|
|---|
| Seal |
|
|---|
| Differential pressure in opening direction |
1500 hPa
|
|---|
| Differential pressure in closing direction |
5000 hPa
|
|---|
| Pressure max. (absolute) |
1000 hPa
|
|---|
| Input voltage(s) |
24 V DC
|
|---|
| Housing |
|
|---|
| Weight |
0.3 kg
|
|---|
| Power consumption max. |
10 W
|
|---|
| Conductance value with laminar flow |
2 l/s
|
|---|
| Conductance value with molecular flow |
0.2 l/s
|
|---|
| Opens against differential pressure of |
1 000 hPa
|
|---|
| Switching frequency |
300 min-1
|
|---|
| Closing/opening time |
7 ms/30 ms
|
|---|
| Protection degree acc. to DIN 40050 |
IP65
|
|---|
| Service life |
2000000 cycles
|
|---|
| Type |
Mini inline valve
|
|---|
| Ambient temperature |
5 – 40 °C
|
|---|
| Version |
Normally closed (n. c.)
|
|---|
