EVD 010 H, Coarse gas dosing Valve
- For slow, manual venting
- Service life: 200000 operating cycles
-
Order number:
PF I22 001
- For slow, manual venting
- Service life: 200000 operating cycles
-
Delivery time:
1-3 days
| Actuator |
|
|---|
| Bakeout temperature |
≤ 100 °C
|
|---|
| Operating pressure min. |
1 · 10-7 hPa
|
|---|
| Tightness |
1 · 10-9 Pa m³/s
|
|---|
| Seal |
|
|---|
| Pressure max. (absolute) |
3000 hPa
|
|---|
| Max. controllable gas flow |
1.7 · 103 hPa·l/s
|
|---|
| Min. controllable gas flow |
4 · 101 hPa·l/s
|
|---|
| Housing |
Aluminum
|
|---|
| Weight |
0.2 kg
|
|---|
| Nominal diameter |
DN 10 ISO-KF
|
|---|
| Opens against differential pressure of |
3 000 hPa
|
|---|
| Type |
Gas control valve
|
|---|
