RPT 200, DN 16 CF-F
  • Order number: PT R37 312
  • 1 · 10<sup>-4</sup> – 1200 hPa
  • Combination of two sensors
  • High accuracy up to atmospheric pressure
  • Profibus DP Interface
  • Delivery time: On request
€1,320.00
Connection flange DN 16 CF-F
Bakeout temperature at the flange ≤ 150 °C
Seal
  • Metal
Pressure max. 4000 hPa
I/O interfaces RS-485, Profibus DP
Input voltage(s) 24 V DC
Full scale 1200 hPa
Weight 225 g
Filament Tungsten
Power consumption max. 4 W
Materials in contact with media
  • Stainless steel
  • Tungsten
  • Gold
  • Silicon oxide
  • Glass
Measuring range 1E-4 – 1.2E3 hPa
Accuracy of measurement in range 1 10 % (2E-3 hPa – 4E1 hPa)
Accuracy of measurement in range 2 0.3 % (full scale) (4E1 hPa – 1.2E3 hPa)
Measurement cable length 100 m
Measuring method
  • Piezo
  • Pirani
Measuring cycle 10 ms
Protection degree
  • IP54
Temperature: Storage -40 – 65 °C
Ambient temperature 5 – 60 °C
Repeatability in range 1 1 % (1E-3 hPa – 1E0 hPa)
Repeatability in range 2 0.1 % (full scale) (1E1 hPa – 1 200 hPa)
Dimension Image
