MPT 200 AR, DN 40 ISO-KF
  • Order number: PT R40 151
  • Customizable to vacuum application
  • Analog output and set points
  • Delivery time: 5 weeks
€1,220.00
Anode
  • Mo
Bakeout temperature at the flange160 °C
Seal
  • Metal
Pressure max.10000 hPa
I/O interfacesRS-485, analog 0 – 10 V
AttributeCold Cathode sensor can be switched on and off via interface
Precision: 1 · 10-8 – 2 · 10-3 hPa± 25 %
Precision: 10 – 1000 hPa± 30 %
Precision: 2 · 10-3 – 10 hPa± 10 %
Weight580 g
Materials in contact with mediaTungsten, stainless steel, nickel, molybdenum, glass
Measuring range5E-9 – 1E3 hPa
Measurement cable length100 m
Measuring methodPirani/Cold Cathode
Measuring cycle10 ms
Nominal diameterDN 40 ISO-KF
Protection degreeIP54
Cold cathode sensor controlCold Cathode sensor can be switched on and off via interface
Temperature: Storage-40 – 65 °C
Ambient temperature5 – 60 °C
Supply: power consumption3.7 W
Supply: Voltage V DC24 V DC
Supply: consumption max.3.7 W
Repeatability: 1 · 10-2 – 10 hPa± 2 %
Repeatability: 1 · 10-8 – 1 · 10-2 hPa± 7 %
