CMR 361, 1000 hPa F.S.
- Flange size DN 8 VCR
- Measurement range from 1 · 10-1 – 1100 hPa
- Minimal zero drift
- Sensor in ceramic technology
- No memory effects
- Materials employed have identical temperature coefficients
- Precise temperature compensation
- Calibration test report included in delivery
- Order number: PT R24 603
- Flange size DN 8 VCR
- Measurement range from 1 · 10<sup>-1</sup> – 1100 hPa
- Minimal zero drift
- Sensor in ceramic technology
- No memory effects
- Materials employed have identical temperature coefficients
- Precise temperature compensation
- Calibration test report included in delivery
- Delivery time: On request
| Resolution | 0.003 % F.S. |
|---|---|
| Output signal: Measuring range | 1 – 9.8 V |
| Output signal: Minimum load | 10 kΩ |
| Bakeout temperature at the flange | 110 °C |
| Pressure max. | 3000 hPa |
| Full scale | 1000 hPa |
| Precision: % of measurement | 0.2 % |
| Weight | 370 g |
| Materials in contact with media | Ceramics (Al2O3 = 99.5 %) |
| Diaphragm and measuring chamber | Ceramics (Al2O3 = 99.5 %) |
| Measuring range | 1E-1 – 1.1E3 hPa |
| Measurement cable length | 120 m |
| Nominal diameter | Cajon 8 VCR |
| Response time | 30 ms |
| Pipe and flange | Stainless steel |
| Protection degree | IP30 |
| Temperature: Storage | -40 – 65 °C |
| Temperature effect: on range | 0.01% of measured value/ °C |
| Temperature effect: on zero point | 0,005 % F.S./°C |
| Ambient temperature | 5 – 50 °C |
| Supply: Voltage V DC | 14 – 30 V DC |
| Supply: consumption max. | ≤ 1 W |
| Volume | ≤ 3.6 cm³ |
