SVV 025 HA, HV Gate valve
- High conductance due to free clearance
- Vulcanized valve disk seal
- Service life: 50000 operating cycles
-
PF D41 000
- High conductance due to free clearance
- Vulcanized valve disk seal
- Service life: 50000 operating cycles
- Delivery time: On request
Global-No. 2000025707
| Connection flange | DN 25 ISO-KF |
|---|---|
| Actuator | Toggle lever |
| Bakeout temperature: actuator | 80 °C |
| Bakeout temperature: housing | 100 °C |
| Tightness | 1 · 10-10 Pa m³/s |
| Seal: Housing | FKM |
| Seal: Valve seat | FKM |
| Differential pressure in opening direction | 1000 hPa |
| Differential pressure in closing direction | 1000 hPa |
| Pressure max. (absolute) | 1000 hPa |
| Pressure min. | 1 · 10-7 hPa |
| Feedthrough | Slideway |
| Input voltage(s) | None |
| Housing | Aluminum |
| Weight | 0.4 kg |
| Conductance value with molecular flow | 34 l/s |
| Opens against differential pressure of | 30 hPa |
| Service life | 50000 cycles |
| Type | HV gate valve |
| Valve plate | Stainless steel |
| Name | Category | Language | Filesize | |
|---|---|---|---|---|
| 3D Step PFD41000.stp |
3D CAD | 1388 kB |
